N/us 1.6.009.013

C/146000, C/146100, C/146200

3/10

Our policy is one of continued research and development. We therefore reserve the right to amend,

without notice, the specifications given in this document.

For complete cylinder dimensions see page 10.

Type

Ø

A

CA

CB

CC

CD

CE

CF

CG

CH

D

E

EA

Weight

Weight

±0.05

at 0 mm

per 100 mm

C/146225/...

25

3.94

1.77

3.54

M6-14*

1.42

1.65

2.60

2.36

3.35

1/8 NPT

5.91

2.76

3.3 lbs.

0.44 lbs.

(100)

(45)

(90)

M6-14*

(36)

(42)

(66)

(60)

(85)

G1/8

(150)

(70)

1.50 kg

0.20 kg

C/146232/...

32

4.72

2.36

4.72

M8-16*

1.50

1.97

3.15

2.95

3.86

1/4 NPT

7.09

3.54

6 lbs.

0.88 lbs.

(120)

(60)

(120)

M8-16*

(38)

(50)

(80)

(75)

(98)

G1/4

(180)

(90)

2.80 kg

0.40 kg

C/146240/...

40

5.91

3.15

5.91

M8-16*

1.65

2.26

3.74

3.62

4.65

1/4 NPT

8.46

4.53

10 lbs.

1 lbs.

(150)

(80)

(150)

M8-16*

(42)

(57.5)

(95)

(92)

(118)

G1/4

(215)

(115)

4.50 kg

0.45 kg

C/146250/...

50

7.09

3.54

7.09

M10-20*

1.73

2.64

4.39

3.94

5.20

3/8 NPT

9.84

5.31

18 lbs.

2 lbs.

(180)

(90)

(180)

M10-20*

(44)

(67)

(111.5)

(100)

(132)

G3/8

(250)

(135)

8.20 kg

0.90 kg

C/146263/...

63

8.46

4.72

9.45

M10-20*

1.85

2.93

5.00

4.33

5.51

1/2 NPT

12.60

7.87

28 lbs.

2.2 lbs.

(215)

(120)

(240)

M10-20*

(47)

(74.5)

(127)

(110)

(140)

G1/2

(320)

(200)

12.50 kg

1.00 kg

*1 deep

9

8

Center bore Ø 6

H7

. 4 deep

For lubrication

EA

CA

CB

8

9

E

A

2 x A + Stroke

CG

CC

C

D

C

F

C

E

CH

Stroke

(both sides)

D

C/146200 – cylinder with precision roller guide (ø 25 to 63 mm)

Cylinder with precision roller guide

C/146200 cylinder ø 25 to 63 mm
