C/146000, C/146100, C/146200

3/10

N/us 1.6.009.012

Our policy is one of continued research and development. We therefore reserve the right to amend,

without notice, the specifications given in this document.

C/146180/MD – cylinder with external adjustable guide and double carriages (ø 80 mm)

260

2 x A + X + Stroke

X

Type

Ø

A

X min.

X max.

Weight at 0 mm

Weight per 100 mm

C/146180/D

80

10.53 (260)

15.4 (390)

19.7 (500)

35 lbs. (15.90 kg)

3.3 lbs. (1.50 kg)
