N/us 1.6.009.015

C/146000, C/146100, C/146200

3/10

Our policy is one of continued research and development. We therefore reserve the right to amend,

without notice, the specifications given in this document.

A

FD

FE

FB

FC

F

N

F

M

2 x A + Stroke

FA

F

G

F

F

FK

FL

FJ

FH

8

Stroke

8

Center bore ø 6

.4 deep

H7

Type

Ø

A

FA

FB

FC

FD

FE

FF

FG

FH

FJ

FK

FL

FM

FN

Weight

Weight

±0.05

at 0 mm

per 100 mm

C/146225/PM/..

25

3.94

5.12

3.54

2.76

1.77

M6

2.83

2.36

0.28

2.40

1.77

0.39

2.36

1.42

4 lbs.

0.88 lbs.

(100)

(130)

(90)

(70)

(45)

M6

(72)

(60)

(7)

(61)

(45)

(10)

(60)

(36)

1.90 kg

0.40 kg

C/146232/PM/..

32

4.72

6.30

4.72

3.54

2.36

M8

3.62

2.95

0.30

3.13

2.24

0.47

2.99

1.81

6.4 lbs.

1.1 lbs.

(120)

(160)

(120)

(90)

(60)

M8

(92)

(75)

(7.5)

(79.5)

(57)

(12)

(76)

(46)

2.90 kg

0.50 kg

C/146240/PM/..

40

5.91

8.46

5.91

4.53

3.15

M8

4.13

3.62

0.30

3.37

2.48

0.47

3.52

2.07

10.4 lbs.

1.4 lbs.

(150)

(215)

(150)

(115)

(80)

M8

(105)

(92)

(7.5)

(85.5)

(63)

(12)

(89.5)

(52.5)

4.70 kg

0.65 kg

C/146250/PM/..

50

7.09

9.84

7.09

5.31

3.54

M10

5.16

3.94

0.37

4.29

3.31

0.59

4.33

2.58

18.7 lbs.

2.5 lbs.

(180)

(250)

(180)

(135)

(90)

M10

(131)

(100)

(9.5)

(109)

(84)

(15)

(110)

(65.5)

8.50 kg

1.10 kg

C/146263/PM/..

63

8.46

12.60

9.45

3.94

4.72

M10

5.51

4.33

0.37

4.55

3.56

0.59

4.92

2.95

24 lbs.

3 lbs.

(215)

(320)

(240)

(100)

(120)

M10

(140)

(110)

(9.5)

(115.5)

(90.5)

(15)

(125)

(75)

11.0 kg

1.40 kg

Note: stroke max. ш 25 = 900. ш 32 & 40 = 1500. ø 50 & 63 = 2600

Cylinder with added caged ball

linear motion guide

C/146200/PM

ø 25 to 63 mm
