CS5467
DS714F3 33
8.2.13 Control (Ctrl) – Address: 28
Default = 0
PC[7:0] Phase compensation for channel 2. Sets a delay in voltage relative to current. Phase is
signed and in the range of -1.0
 value  1.0 sample (OWR) intervals.
I1gain (I2gain) Sets the gain of the current1 (current2) input.
0 = Gain is set for ±250mV range.
1 = Gain is set for ±50mV range.
STOP Terminates E
2
PROM command sequence (if used).
0 = No Action
1 = Stop E
2
PROM Commands.
INTOD Converts INT output pin to an open drain output.
0 = Normal Output
1 = Open-drain Output
NOCPU Saves power by disabling the CPUCLK output pin.
0 = CPUCLK Enabled
1 = CPUCLK Disabled
NOOSC Disables the crystal oscillator, making XIN a logic-level input.
0 = Crystal Oscillator Enabled
1 = Crystal Oscillator Disabled
23 22 21 20 19 18 17 16
PC7 PC6 PC5 PC4 PC3 PC2 PC1 PC0
15 14 13 12 11 10 9 8
- - - I2gain - - - STOP
7 6 5 4 3 2 1 0
- - I1gain INTOD - NOCPU NOOSC -
