CS5374
CS5374
5
THERMAL CHARACTERISTICS
ANALOG CHARACTERISTICS
Notes: 7. Common mode signals pass through the differential amplifier architecture and are rejected by the
modulator CMRR.
8. Output impedance characteristics are approximate and can vary up to ±30% depending on process
parameters.
Parameter
Symbol Min Typ
Max
Unit
Ambient Operating Temperature
T
A
-10
-
70
°C
Storage Temperature Range
T
STR
-65
-
150
°C
Allowable Junction Temperature
T
JCT
-
-
125
°C
Junction to Ambient Thermal Impedance (4-layer PCB)
θ
JA
-
26
-
°C / W
Parameter
Symbol Min Typ
Max
Unit
Amplifier Inputs
Signal Frequencies
BW
DC
-
2000
Hz
Differential Gain
GAIN
x1
-
x64
Common Mode Gain
(
GAIN
CM
-
x1
-
Common Mode Voltage
V
cm
-
(VA-)+2.5
-
V
Voltage Range (Signal + Vcm)
x1
x2 - x64
V
IN
(VA-)+0.7
(VA-)+0.7
-
-
(VA+)-1.25
(VA+)-1.75
V
Full Scale Differential Input
x1
x2
x4
x8
x16
x32
x64
V
INFS
-
-
-
-
-
-
-
-
-
-
-
-
-
-
5
2.5
1.25
625
312.5
156.25
78.125
V
pp
V
pp
V
pp
mV
pp
mV
pp
mV
pp
mV
pp
Differential Input Impedance
Z
INDIFF
-
1, 20
-
T
Ω, pF
Common Mode Input Impedance
Z
INCM
-
0.5, 40
-
T
Ω, pF
Input Bias Current
I
IN
-
1
40
pA
Amplifier Outputs
Full Scale Output, Differential
V
OUT
-
-
5
V
pp
Output Voltage Range (Signal + Vcm)
V
RNG
(VA-)+0.5
-
(VA+)-0.5
V
Output Impedance
(
)
Z
OUT
-
40
-
Ω
Output Impedance Drift
(
)
Z
TC
-
0.38
-
Ω/°C
Output Current
I
OUT
-
-
+25
mA
Load Capacitance
C
L
-
-
100
nF
Guard Outputs
Guard Output Voltage
V
GUARD
-
V
cm
-
V
Guard Output Impedance
(
)
ZG
OUT
-
500
-
Ω
Guard Output Current
IG
OUT
-
-
40
μA
Guard Load Capacitance
CG
L
-
-
100
pF
