5.5 Example: CS5374 Configuration by the CS5376A SPI 2 Port
The CS5374 SPI port was designed to connect to
the CS5376A secondary SPI 2 port as shown in
Figure 12 on page 15.
The CS5376A SPI 2 hardware is controlled by
writing internal digital filter registers SPI2CTRL,
SPI2CMD, and SPI2DAT through a primary SPI 1
port. Chip selects are enabled by writing the
GPCFG0 digital filter register prior to initiating
SPI 2 transactions.
Configuring CS5374 using SPI 2 is more complex
than using an external SPI master, but has the ad-
vantage of a single standardized hardware interface
(the primary SPI 1 port on CS5376A) to control
the entire chipset.
5.5.1 CS5376A SPI 1 Transactions
The CS5376A primary SPI 1 port is controlled by
an external SPI master writing commands and data
into the SPI 1 registers (SPICMD, SPIDAT1, and
SPIDAT2). Serial transactions into the CS5376A
primary SPI 1 port start with an SPI opcode, fol-
lowed by an SPI address, and then data bytes writ-
ten starting at that SPI address. These data bytes
contain internal commands to write the CS5376A
digital filter registers that control the SPI 2 hard-
ware and enable the chip selects.
A full description of how to write the CS5376A in-
ternal digital filter registers using the primary SPI 1
port is described in the CS5376A data sheet.
GPIO Register
Certain GPIO pins on the CS5376A have dual-use
as chip selects for the SPI 2 port. The GPIO0:CS0
and GPIO1:CS1 pins are recommended as dedicat-
ed chip selects when connecting two CS5374 de-
vices to the CS5376A SPI 2 port. To operate the
CS0 and CS1 pins as SPI 2 chip selects they must
be programmed as outputs in the GPCFG0 digital
filter register, as shown in Table 5.
SPI2 Registers
Three digital filter registers control the CS5376A
SPI 2 hardware. The SPI2CMD register is 16-bits
wide and contains the first two bytes of the SPI 2
transaction, the SPI opcode and SPI address, in the
lower two bytes (i.e. 0x000204).
Table 5. Example CS5376A SPI 1 Transactions to Write and Read the GPCFG0 Register
Transaction CS5376A Primary SPI 1 Write Description
01 MOSI: 02 | 03 | 00 00 01 | 00 00 0E | 03 FF FF
MISO: -----------------------------------------------------------
SPI Command : 0x02 : Write
SPI Address : 0x03 : SPICMD
SPICMD : 0x000001 : Write Register
SPIDAT1 : 0x00000E : GPCFG0
SPIDAT2 : 0x03FFFF : CS as Output
02 Delay 1ms, monitor SINT, or poll E2DREQ See the CS5376A data sheet.
03 MOSI: 02 | 03 | 00 00 02 | 00 00 0E | 00 00 00
MISO: -----------------------------------------------------------
SPI Command : 0x02 : Write
SPI Address : 0x03 : SPICMD
SPICMD : 0x000002: Read Register
SPIDAT1 : 0x00000E : GPCFG0
SPIDAT2 : 0x000000 : Dummy
04 Delay 1ms, monitor SINT, or poll E2DREQ See the CS5376A data sheet.
05 MOSI: 03 | 06 |---------------|
MISO: -------------| 03 FF FF |
SPI Command : 0x03 : Read
SPI Address : 0x06 : SPIDAT1
SPIDAT1 : 0x03FFFF : GPCFG0
