CS5374
CS5374
38
9.4 ADCCFG: 0x03
9.5 PWRCFG: 0x04
(MSB)7 6 5 4 3 2 1 (LSB)0
OFST HP PWDN2 PWDN1 --- --- --- ---
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
Figure 23. Modulator 1 & 2 Configuration Register ADCCFG
Bit definitions:
7 OFST Modulator Offset
(add -60mV to Channel 1,
add -35mV to Channel 2)
1: disable
0: enable
6 HP Modulator High Precision
1: enable
0: disable
5 PWDN2 Modulator 2 Power Down
1: enable
0: disable
4 PWDN1 Modulator 1 Power Down
1: enable
0: disable
3:0 --- Reserved
Address: 0x03
-- Not defined
(read as 0)
R Readable
W Writable
R/W Readable
and Writable
Bits in bottom rows
are reset condition
Reset Condition : 0000_0000 (0x00) : Default value
Normal Operation : 0100_0000 (0x40) : HP mode enabled
Power Down Operation : 0011_0000 (0x30) : PWDN enabled
