Differential Amplifier Analog Outputs

OUT1–,

OUT1+

46
47

O

Channel 1 differential analog output.

GUARD1

48

O

Guard output voltage for analog input Channel 1.

GUARD2

13

O

Guard output voltage for analog input Channel 2.

OUT2+,

OUT2–

14
15

O

Channel 2 differential analog output.

Modulator Analog Inputs

INR1+,

INF1+,
INF1–,

INR1–

42
43
44
45

I

Channel 1 analog differential rough and fine inputs.
From the Channel 1 differential anti-alias filter.

INR2–,

INF2–,
INF2+,

INR2+

16
17
18
19

I

Channel 2 analog differential rough and fine inputs.
From the Channel 2 differential anti-alias filter.

Voltage Reference

VREF+,

VREF–

21
22

I

Voltage reference input.
Refer to the Specified Operating Conditions.

Serial Interface

CS

25

I

Chip select. Active low.

SCLK

26

I

Serial clock.

SDI

27

I

Serial data in to device.

SDO

28

O

Serial data out of device.

Modulator Interface

MCLK

36

I

Modulator clock input.

MSYNC

35

I

Modulator sync input.

MFLAG1

33

O

Channel 1 modulator flag output.

MDATA1

34

O

Channel 1 modulator data output.

MFLAG2

29

O

Channel 2 modulator flag output.

MDATA2

30

O

Channel 2 modulator data output.

Device Reset

RST

37

I

Reset. Active low.

Other

NC

20, 23, 24,

38, 41

---

No connect.

DNC

5, 8

---

Do Not Connect.

Thermal Pad

49

I

Connect to VA–. Do not connect to GND.
