1.
CHARACTERISTICS AND SPECIFICATIONS
•
Min/Max characteristics and specifications are guaranteed over the Specified Operating Conditions.
•
Typical performance characteristics and specifications are derived from measurements taken at nom-
inal supply voltages and T
A
= 25
°C.
•
GND = 0 V, all voltages with respect to 0 V.
•
Device connected as shown in
and
unless otherwise noted.
SPECIFIED OPERATING CONDITIONS
Notes: 1. VA- must always be the most-negative input voltage to avoid potential SCR latch-up conditions.
2. By design, a 2.500 V voltage reference input results in the best signal-to-noise performance.
3. Channel-to-channel gain accuracy is directly proportional to the voltage reference absolute accuracy.
4. VREF inputs must satisfy: VA-
≤ VREF- < VREF+ ≤ VA+.
ABSOLUTE MAXIMUM RATINGS
WARNING: Operation at or beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
Notes: 5. Transient currents up to 100mA will not cause SCR latch-up.
6. Includes continuous over-voltage conditions on the analog input pins.
Parameter
Symbol Min Nom
Max
Unit
Bipolar Power Supplies
Positive Analog
+2%
VA+
2.45
2.50
2.55
V
Negative Analog
(
) +2%
VA-
-2.45
-2.50
-2.55
V
Positive Digital
+3%
VD
3.20
3.30
3.40
V
Voltage Reference
[VREF+] - [VREF-]
)
VREF
-
2.500
-
V
VREF-
)
VREF-
-
VA -
-
V
Thermal
Ambient Operating Temperature
-CNZ
T
A
-10
25
70
°C
Parameter
Symbol Min
Max
Unit
DC Power Supplies
Positive Analog
Negative Analog
Digital
VA+
VA-
VD
-0.3
-6.8
-0.3
6.8
0.3
6.8
V
V
V
Analog Supply Differential
[(VA+) - (VA-)]
VA
DIFF
-
6.8
V
Digital Supply Differential
[(VD) - (VA-)]
VD
DIFF
-
6.8
V
Input Current, Any Pin Except Supplies
(
I
IN
-
+10
mA
Input Current, Power Supplies
(
I
PWR
-
+50
mA
Output Current
(
I
OUT
-
+25
mA
Power Dissipation
PD
-
500
mW
Analog Input Voltages
V
INA
(VA-)-0.5
(VA+)+0.5
V
Digital Input Voltages
V
IND
-0.5
(VD)+0.5
V
Storage Temperature Range
T
STG
-65
150
°C
