Page 11
CS5374
CS5374
11
DIGITAL CHARACTERISTICS (CONT.)
Notes: 23. MCLK is generated by the CS5376A digital filter. If MCLK is disabled, the CS5374 device automatically
enters a power-down state. See Power Supply Characteristics for typical power-down timing.
24. MSYNC is generated by the CS5376A digital filter and is latched by CS5374 on MCLK falling edge,
synchronization instant (
t
0
) is on the next MCLK rising edge.
25. Decimated, filtered, and offset-corrected 24-bit output word from the CS5376A digital filter.
Parameter
Symbol Min Typ
Max
Unit
Master Clock Input
MCLK Frequency
(
)
f
MCLK
-
2.048
-
MHz
MCLK Duty Cycle
MCLK
DTC
40
-
60
%
MCLK Rise Time
t
RISE
-
-
50
ns
MCLK Fall Time
t
FALL
-
-
50
ns
MCLK Jitter (in-band or aliased in-band)
MCLK
IBJ
-
-
300
ps
MCLK Jitter (out-of-band)
MCLK
OBJ
-
-
1
ns
Master Sync Input
MSYNC Setup Time to MCLK Falling
(
)
t
MSS
20
366
-
ns
MSYNC Period
(
)
t
MSYNC
40
976
-
ns
MSYNC Hold Time after MCLK Falling
(
)
t
MSH
20
610
-
ns
MDATA Output
MDATA Output Bit Rate
f
MDATA
-
512
-
kbits/s
MDATA Output One’s Density Range
(
)
MDAT
1D
14
-
86
%
Full-scale Output Code, Offset Corrected
(
)
MDAT
FS
0xA2E736
-
0x5D18CA
MCLK
MSYNC
t 0
t
MSS
1 / f
MCLK
t
MSYNC
t
MSH
MDATA
MFLAG
1 / f
MDATA
Figure 7. MCLK / MSYNC Timing Detail
