D-20-9 / D-21-9 GB
WIKA Additional Instructions Pressure Transmitter with CANopen Interface D-20-9 / D-21-9 34
61A0h AI Filter Type
Object description
The object defines the type of filter to be used for calculation.
The implemented filter is manufacturer specific.
Entry description
Sub-Index 00h
Name number of entries
Access ro
PDO Mapping No
Data Type UNSIGNED 8
Default Value 01h
Sub-Index 01h
Name AI Filter Type
Access ro
PDO Mapping No
Data Type UNSIGNED 8
Default Value 64h
61A1h AI Filter Constant
Object description
Defines the number of steps used for the filter calculation.
Allowed values for the filter constant are 1 to 128.
Entry description
Sub-Index 00h
Name number of entries
Access ro
PDO Mapping No
Data Type UNSIGNED 8
Default Value 01h
Sub-Index 01h
Name AI Filter Constant
Access rw
PDO Mapping No
Data Type UNSIGNED 8
Default Value 8h
