D-20-9 / D-21-9 GB
WIKA Additional Instructions Pressure Transmitter with CANopen Interface D-20-9 / D-21-9 27
5. Object Dictionary – Device Profile Area
(according CiA DS404 V1.2)
7100h AI Input FV
Object description
This object represents the compensated pressure value, which is not yet scaled to the physical unit of the
quantity being measured.
Entry description
Sub-Index 00h
Name number of entries
Access ro
PDO Mapping No
Data Type UNSIGNED 8
Default Value 01h
Sub-Index 01h
Name AI Input FV 1
Access ro
PDO Mapping No
Data Type UNSIGNED 16
Default Value 10000 – 60000
7120h AI Input Scaling 1 FV
Object description
This object defines the field value of the first calibration point for the analogue input channel. It is scaled in
physical unit of field value.
Entry description
Sub-Index 00h
Name number of entries
Access ro
PDO Mapping No
Data Type UNSIGNED 8
Default Value 01h
Sub-Index 01h
Name AI Input Scaling 1 FV 1
Access ro
PDO Mapping No
Data Type UNSIGNED 16
Default Value 10000
