D-20-9 / D-21-9 GB
WIKA Additional Instructions Pressure Transmitter with CANopen Interface D-20-9 / D-21-9 28
6121h AI Input Scaling 1 PV
Object description
This object defines the process value of the first calibration point for the analogue input channel. It is scaled in
physical unit of process value.
Entry description
Sub-Index 00h
Name number of entries
Access ro
PDO Mapping No
Data Type UNSIGNED 8
Default Value 01h
Sub-Index 01h
Name AI Input Scaling 1 PV 1
Access rw
PDO Mapping No
Data Type float
Default Value No
Changed parameters are not automatically stored, but they have to be stored via object 1010h Store
Parameters.
Furthermore the device can be reset to the factory settings via object 1011h Restore Default Parameters.
7122h AI Input Scaling 2 FV
Object description
This object defines the field value of the second calibration point for the analogue input channel. It is scaled in
physical unit of field value.
Entry description
Sub-Index 00h
Name number of entries
Access ro
PDO Mapping No
Data Type UNSIGNED 8
Default Value 01h
Sub-Index 01h
Name AI Input Scaling 2 FV 1
Access rw
PDO Mapping No
Data Type UNSIGNED 16
Default Value 60000
