92 VP-790 Protocol - API Functions
2.85 PiP/Multiple Unit Operation Mode
2.85.1 byOsdPIPEBOperationModeSet
API index: 3172
Switches between PiP mode and Multiple Unit Mode. Multiple Unit mode does not
support PiP, whereas PiP mode does not support Edge Blend and PC tool
generated warp maps.
Input Parameters
Name Type Range Description
Value UWORD32 0: PiP Mode
1: Multiple Unit Mode
Sets the operation mode.
Return Values
Name Type Range Description
Status BYTE 0x00-0xFF 0 if successful, error code otherwise
2.85.2 byOsdPIPEBOperationModeGet
API index: 3173
Retrieves the operation mode.
Input Parameters
Name Type Range Description
Option BYTE 0: From cache
1: From SPD
Retrieval method
Return Values
Name Type Range Description
Status BYTE 0x00-0xFF 0 if successful, error code otherwise
Value UWORD32 0: Off
1: S-Curve
2: Align Pattern
Retrieves the operation mode set.
2.85.3 byOsdPIPEBOperationModeSave
API index: 3174
Saves the operation mode from cache into the SPD.
Input Parameters
None
Return Values
Name Type Range Description
Status BYTE 0x00-0xFF 0 if successful, error code otherwise
