Kramer Protocol
43
43
Read audio connection AUD? OUT
Short form: A? OUT
AUD? *
AUD IN>OUT
AUD IN>1, IN>2, …
Parameters Description:
IN = Input number or '0' to disconnect output.
' > ' = Connection character between in and out parameters.
OUT = Output number or '*' for all outputs.
Examples:
Switch Video and Audio input 3 to output 7 #AV 3>7CR ~AV 3>7 OKCRLF
Switch Video input 2 to output 4 #V 2>4CR ~VID 2>4 OKCRLF
Switch Video input 4 to output 2 in machine
number 6
#6@VID 4>2CR ~6@VID 4>2 OKCRLF
Disconnect Video and Audio Output 4 #AV 0>4CR ~AV 0>4 OKCRLF
Switch Video Input 3 to All Outputs #V 3>*CR ~VID 3>* OKCRLF
Chaining Multiple
commands*
#AV 1>* | V 3>4, 2>2, 82>1, 0>2 |V 82>3| A 0>1 | V? * CR
First switch all Audio and video outputs from input 1,
Then switch video input 3 to output 4, video input 2 to output 2,
video input and disconnect video output 2.
Then switch audio input 3 to output 2,
Then disconnect audio output 1.
Then get status of all links (assume this is 4x4 matrix).
Commands processing start after entering CR, response will sent for
each command after processing it.
~AV 1>* OKCRLF
~VID 1>2, 3>4
OKCRLF
~VID 82>3 ERR###
CRLF
~AUD 0>1 OKCRLF
~V 1>1, 0>2, 1>3, 3>4
CRLF
Signal Status commands
Command Syntax Response
Change signal status ------------------- SIGNAL INPUT, STATUS
Get signal status SIGNAL? INPUT SIGNAL INPUT, STATUS
Parameters Description:
INPUT = Input number, ‘*’ for all.
STATUS = Signal state:
"0" or "off" for not existent signal.
"1" or "on" for existent signal.
Preset commands
Command Syntax Response
Store current
connections to preset
PRST-STO PRESET
Short form: PSTO PRESET
PRST-STO PRESET RESULT
Recall saved preset PRST-RCL PRESET
Short form: PRCL PRESET
PRST-RCL PRESET RESULT
Delete saved preset PRST-DEL PRESET
Short form: PDEL PRESET
PRST-DEL PRESET RESULT
