Technical Specifications
35
35
12
Technical Specifications
Technical specifications of the VP-8x8TP are shown in
Table 3: Technical Specifications
INPUTS:
of the VP-8x8TP 8x8 UXGA/Audio Matrix Switcher
8 VGA on 15-pin HD connectors (VGA through UXGA)
8 unbalanced stereo audio on 3.5mm mini jacks
OUTPUTS:
8 RJ-45 connectors
MAX. OUTPUT LEVEL:
VIDEO: 1.9Vpp
AUDIO: 3Vpp
RESOLUTION:
Up to UXGA, 1080p
AUDIO BANDWIDTH:
18kHz (–3dB)
DIFF. GAIN:
1.8%
DIFF. PHASE:
0.3Deg
K-FACTOR:
<0.05%
S/N RATIO:
VIDEO: 60dB @5MHz
AUDIO: 81dB @1kHz
CROSSTALK (all hostile):
VIDEO: –46dB @5MHz
AUDIO: <–72dB @1kHz
CONTROLS:
Front panel buttons, RS-232, RS-485, Ethernet, Infrared
COUPLING:
VIDEO: AC
AUDIO: AC
AUDIO THD + NOISE:
0.035% @1kHz
AUDIO 2nd HARMONIC:
0.002% @1kHz
TRANSMISSION RANGE:
>100m (330ft)
OPERATING TEMPERATURE:
0° to +55°C (32° to 131°F)
STORAGE TEMPERATURE:
–45° to +72°C (–49° to 162°F)
HUMIDITY:
10% to 90%, RHL non-condensing
POWER CONSUMPTION:
100-240V AC, 68VA
DIMENSIONS:
19" x 7.5" x 1U (48.3cm x 19cm x 1U) W, D, H
WEIGHT:
2.6kg (5.7lbs) approx
ACCESSORIES:
Power cord, Windows
®
-based control software, external remote IR receiver
cable
13
Default Communication Parameters
lists the default communication parameters as used in the VP-8x8TP.
Table 4: Default Communication Parameters
RS-232
Protocol 2000
Protocol 3000 (Default)
Baud Rate:
9600
Baud Rate:
115,200
Data Bits:
8
Data Bits:
8
Stop Bits:
1
Stop Bits:
1
Parity:
None
Parity:
None
Command Format:
HEX
Command Format:
ASCII
Example (Output 1 to Input 1):
0x01, 0x81, 0x81, 0x81
Example (Output 1 to Input 1):
#AV 1>1
1 Specifications are subject to change without notice
2 P/N: C-A35M/IRR-50
