Operating the VP-8x8TP 8x8 UXGA/Audio Matrix Switcher
17
17
7 Operating the VP-8x8TP 8x8 UXGA/Audio Matrix Switcher
This section includes:
• Switching Inputs and Output (see
Section 7.1 )
• The 7-segment Display Modes (see
Section 7.2 )
• Confirming Settings (see
Section 7.3 )
• Storing/Recalling Input-Output Configurations (see
Section 7.4 )
• Locking the Front Panel (see
Section 7.5 )
• Choosing the Audio-Follow-Video or Breakaway Option (see
Section 7.6 )
• Setting the Audio Input Gain (see
Section 7.7 )
• Using the IR Transmitter (see
Section 7.8 )
7.1 Switching Inputs and Outputs
7.1.1 Switching an Input to an Output
To switch an input to an output:
1. Press the required OUTPUT button.
The input number below the selected output on the INPUT 7-segment display
flashes.
2. Press an INPUT button to select the input to switch to the output.
The selected input number appears on the 7-segment display.
Incomplete operations on the VP-8x8TP timeout after 15 seconds
7.1.2 Switching an Input to all Outputs
To switch an input to all outputs:
1. Press the ALL button.
The 7-segment display flashes.
2. Press an INPUT button to select the input to switch to all outputs.
The selected input is switched to all outputs and the selected input appears on
all outputs of the 7-segment display.
7.1.3 Disconnecting an Input from an Output
To disconnect an input from an output:
1. Press the required OUTPUT button.
The selected output flashes on the 7-segment display.
2. Press the OFF button.
The selected output is disconnected and displays 0 on the 7-segment display.
