Tables of Hex Codes for Serial Communication (Protocol 2000)
38
Table 6: VP-8x8TP Audio Signal Codes
OUT 1 OUT 2 OUT 3 OUT 4 OUT 5 OUT 6 OUT 7 OUT 8
IN 1 #A 1>1 CR #A 1>2 CR #A 1>3 CR #A 1>4 CR #A 1>5 CR #A 1>6 CR #A 1>7 CR #A 1>8 CR
IN 2 #A 2>1 CR #A 2>2 CR #A 2>3 CR #A 2>4 CR #A 2>5 CR #A 2>6 CR #A 2>7 CR #A 2>8 CR
IN 3 #A 3>1 CR #A 3>2 CR #A 3>3 CR #A 3>4 CR #A 3>5 CR #A 3>6 CR #A 3>7 CR #A 3>8 CR
IN 4 #A 4>1 CR #A 4>2 CR #A 4>3 CR #A 4>4 CR #A 4>5 CR #A 4>6 CR #A 4>7 CR #A 4>8 CR
IN 5 #A 5>1 CR #A 5>2 CR #A 5>3 CR #A 5>4 CR #A 5>5 CR #A 5>6 CR #A 5>7 CR #A 5>8 CR
IN 6 #A 6>1 CR #A 6>2 CR #A 6>3 CR #A 6>4 CR #A 6>5 CR #A 6>6 CR #A 6>7 CR #A 6>8 CR
IN 7 #A 7>1 CR #A 7>2 CR #A 7>3 CR #A 7>4 CR #A 7>5 CR #A 7>6 CR #A 7>7 CR #A 7>8 CR
IN 8 #A 8>1 CR #A 8>2 CR #A 8>3 CR #A 8>4 CR #A 8>5 CR #A 8>6 CR #A 8>7 CR #A 8>8 CR
Table 7 lists the codes that set the audio input gain.
Table 7: VP-8x8TP Audio Input Gain Codes
INPUT 1 INPUT 5 INPUT X*
Level
[Rel]
#AUD-LVL 1,1, -100CR … #AUD-LVL 1,5, -100CR … #AUD-LVL 1,X, -100CR -100dB Mute
…
…
…
#AUD-LVL 1,1, -50CR … #AUD-LVL 1,5, -50CR … #AUD-LVL 1,X, -50CR -50dB
…
…
…
#AUD-LVL 1,1, 0CR … #AUD-LVL 1,5, 0CR … #AUD-LVL 1,X, 0CR 0dB
…
…
…
#AUD-LVL 1,1, 20CR … #AUD-LVL 1,5, 20CR … #AUD-LVL 1,X, 20CR +20dB (Max)
* Where X is the input number from 1 - 8. For example, for channel 7 and relative level -50dB, #AUD-LVL 1,7, -50CR
15 Tables of Hex Codes for Serial Communication (Protocol 2000)
The hex codes listed in this section are used to set video channels for a single
machine (set as Machine 1) connected via either RS-232 or Ethernet. Similar hex
codes are used when the VP-8x8TP is connected via RS-485 and the machine is
set to number 2.
Table 8 lists the Hex codes for switching video channels.
Table 8: VP-8x8TP Hex Codes for Switching Video Channels
Switching Video Channels
OUT 1 OUT 2 OUT 3 OUT 4 OUT 5 OUT 6 OUT 7 OUT 8
IN 1 01 81 81 81 01 81 82 81 01 81 83 81 01 81 84 81 01 81 85 81 01 81 86 81 01 81 87 81 01 81 88 81
IN 2 01 82 81 81 01 82 82 81 01 82 83 81 01 82 84 81 01 82 85 81 01 82 86 81 01 82 87 81 01 82 88 81
IN 3 01 83 81 81 01 83 82 81 01 83 83 81 01 83 84 81 01 83 85 81 01 83 86 81 01 83 87 81 01 83 88 81
IN 4 01 84 81 81 01 84 82 81 01 84 83 81 01 83 84 81 01 84 85 81 01 84 86 81 01 84 87 81 01 84 88 81
IN 5 01 85 81 81 01 85 82 81 01 85 83 81 01 85 84 81 01 85 85 81 01 85 86 81 01 85 87 81 01 85 88 81
IN 6 01 86 81 81 01 86 82 81 01 86 83 81 01 86 84 81 01 86 85 81 01 86 86 81 01 86 87 81 01 86 88 81
IN 7 01 87 81 81 01 87 82 81 01 87 83 81 01 87 84 81 01 87 85 81 01 87 86 81 01 87 87 81 01 87 88 81
IN 8 01 88 81 81 01 88 82 81 01 88 83 81 01 88 84 81 01 88 85 81 01 88 86 81 01 88 87 81 01 88 88 81
Table 9 lists the Hex codes for switching audio channels.
Table 9: VP-8x8TP Hex Codes for Switching Audio Channels
