Is everything in the package?
The package contains the PLT unit, one adapter each for testing air-
displacement pipettes with tips (mounted) or without tips, 2 blind plugs,
3 replacement PE filters for the pipette adapter, an AC adapter, a quality
certificate, and this Operating Manual.

First Steps

Use only the origi-
nal AC adapter!
The instrument's
AC adapter and AC
adapter plug must
be freely accessible,
and separatable
from the power grid
at any time.

Language

Deutsch

English

Español

o.k.

Settings

Language

Contrast

Inspection date

Auto-Power-Off Time

select

back

What to do?

How to do it

Keys to press

Display readout

Connect the AC adapter
to the socket in the back
of the instrument, without
pressing any buttons on the
instrument.

After the AC adappter is
connected, the display
shows the software version
number, the creation date,
and the BRAND logo.
During initial start-up, the
display brings up the "Lan-
guage" indicator after 3 sec.

1.

Connecting the

AC adapter

The language is selected by
turning the select knob.

2.

Selecting the

language

Press the left "OK" button.
The "Settings" menu appears
in the language selected.

The "Back" button leads to
the Main Menu.

3.

Confirming the

language

Language

Deutsch

English

Español

o.k.

After start-up, one can select either to perform the self-test (page 40) or directly begin a
pipette test (page 44).

Powering on
the instru-
ment

Note:

39

V1.40.011

3-Mar-2011

Firmware
