Operating Elements

According to ISO 8655, air-displacement pipettes should be checked regularly.
The BRAND PLT unit offers a safeguard for the periods between calibration intervals.

Single-channel

adapter

"Back"
button

AC adapter

socket

"Start/Execute"

button

Select knob

LED display

Display

USB port

Back of the instrument

The function of the
"Back" button is varied
by pressing for a short
or long time. Pressing
the button for a short
time leads back to a sub-
menu in the next higher
level of the menu hier-
archy. Pressing the but-
ton for a long time leads
back directly to "Ready"
on the Start Menu.

"Back" button

Select knob

In many cases, pressing
the left "Start/Execute"
button as well as the
central knob can be used
to confirm a selection.
For consistency, the left
"Start/Execute" button
is used for confirmation
in this Operating Manual.
