HBH Series (60 Hz)
Weight - Operating (lbs) [kg] 586 [265.8] 644 [292.1] 698 [316.6]
Weight - Packaged (lbs) [kg] 626 [283.9] 684 [310.3] 738 [334.8]
Weight - Corner - Control box/Compressor side (lbs) [kg] 235 [106.6] 254 [115.2] 271 [122.9]
Weight - Corner - Compressor side (lbs) [kg] 101 [45.8] 120 [54.4] 137 [62.1]
Weight - Corner - Blower side side (lbs) [kg] 180 [81.6] 190 [86.2] 200 [90.7]
Weight - Corner - Air Coil side (lbs) [kg] 70 [31.8] 80 [36.3] 90 [40.8]
Model 072 096 120
Compressor Quantity Scroll
Number of Circuits (Compressors) 2
Factory Charge HFC-410a (oz) [kg] per circuit 60 [1.70] 76 [2.15] 80 [2.27]
Blower Motor
Blower Motor Quantity 1
Standard Motor (hp) [kw] 1 [0.75] 2 [1.49] 3 [2.24]
Large Motor (hp)[KW] (2)[1.49] 3[2.24] 5[3.73]
Blower
No. of Blowers 1
Blower Wheel Size D x W (in0 [cm] 12 x 12 [30.48 x 30.48]
Water Connection Size
FPT (in) [mm] 1-1/4" [31.8] 1-1/2" [38.1]
Coax Volume
Volume (US Gallons) [liters] 1.62 [6.13] 1.81 [6.85] 2.40 [9.08]
Condensate Connection Size
FPT (in) [mm] 3/4" [19.1]
Air Coil Data
Air Coil Dimensions H x W (in) [cm] 20 x 54 [50.8 x 137.16] 20 x 64 [50.8 x 162.56]
Air Coil Total Face Area (ft2) [m2] 7.5 [0.70] 8.9 [0.83]
Air Coil Tube Size (in) [cm] 3/8" [0.953]
Air Coil Fin Spacing (fpi) [fins per cm] 14 [5.5]
Air Coil Number of Rows 3
Miscellaneous Data
Filter Standard - 1" [25.4mm] Throwaway (qty)
(in) [cm]
(QTY.4) 16 x20 [40.64 x 50.80]
Weight - Operating (lbs) [kg] 586 [265.8] 644 [292.1] 698 [316.6]
Weight - Packaged (lbs) [kg] 626 [283.9] 684 [310.3] 738 [334.8]
All units have grommet compressor mountings, and 1/2" & 1-3/4" electrical knockouts.
Unit Maximum Water Working
Pressure
Max Pressure PSIG [kPa]
Base Unit 500 [3445]
HBH Corner Weights
Unit Physical Data
HBH072 HBH096 HBH120
