Table 4a: HBH Blower Sheave and Belt Information
Model
Configuration
Return/Supply
Component
Drive Package
A B C D E
72
Left or Right/
Straight or Back
Blower Sheave BK67 X 1" BK85 X 1" BK67 X 1" BK67 X 1" BK67 X 1"
Motor Sheave 1VP34 X 7/8" 1VP34 X 7/8" 1VP44 X 7/8" 1VP34 X 7/8" 1VP44 X 7/8"
Motor 1HP 1HP 1HP 2HP 2HP
Belt B X 46 B X 50 B X 48 B X 46 B X 48
96
Blower Sheave BK67 X 1" BK77 X 1" BK62 X 1" BK67 X 1" BK62 X 1"
Motor Sheave 1VP40 X 7/8" 1VP34 X 7/8" 1VP44 X 7/8" 1VP40 X 7/8" 1VP44 X 7/8"
Motor 2HP 2HP 2HP 3HP 3HP
Belt B X 46 B X 48 B X 46 B X 46 B X 46
120
Blower Sheave BK67 X 1" BK67 X 1" BK67 X 1" BK67 X 1" BK67 X 1"
Motor Sheave 1VP44 X 7/8" 1VP34 X 7/8" 1VP50 X 7/8" 1VP44 X 1-1/8" 1VP50 X 1-1/8"
Motor 3HP 3HP 3HP 5HP 5HP
Belt B X 48 B X 46 B X 48 B X 50 B X 51
Blower Sheave Information
