HBH096 Blower Performance
SCFM
ESP
0.00
0.10
0.20
0.30
0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40
1.50
2400
BHP
0.45
0.50
0.54
0.59
0.63
0.69
0.74
0.80
0.85
0.90
0.94
0.99
1.04
1.10
1.16
1.22
Sheave/Mtr
B
B
B
B
B
A
A
A
A
A
A
A
A
A
C
C
RPM
578
625
665
705
745
785
820
860
895
925
960
990
1020
1050
1080
1110
Turns
Open
5
4
3
2.5
1.5
5.5
5
4
3.5
3
2.5
2
1.5
1
4
3.5
2500
BHP
0.50
0.55
0.59
0.64
0.69
0.75
0.81
0.88
0.92
0.97
1.01
1.06
1.12
1.17
1.23
1.29
Sheave/Mtr
B
B
B
B
A
A
A
A
A
A
A
A
A
C
C
C
RPM
599
645
685
725
765
800
835
875
905
940
970
1005
1035
1060
1090
1120
Turns
Open
4.5
3.5
2.5
2
6
5
4.5
4
3.5
3
2.5
2
1
4.5
3.5
3
2600
BHP
0.55
0.60
0.65
0.69
0.75
0.80
0.86
0.92
0.97
1.02
1.08
1.13
1.19
1.25
1.30
1.36
Sheave/Mtr
B
B
B
B
A
A
A
A
A
A
A
A
A
C
C
C
RPM
625
665
705
740
780
815
850
885
920
950
985
1015
1045
1075
1100
1130
Turns
Open
4
3
2.5
1.5
5.5
5
4.5
3.5
3
2.5
2
1.5
1
4
3.5
3
2700
BHP
0.60
0.65
0.70
0.75
0.80
0.86
0.91
0.97
1.02
1.08
1.14
1.20
1.26
1.32
1.38
1.44
Sheave/Mtr
B
B
B
A
A
A
A
A
A
A
A
A
C
C
C
C
RPM
645
685
725
760
795
830
865
900
930
960
995
1025
1055
1085
1115
1140
Turns
Open
3.5
2.5
2
6
5.5
4.5
4
3.5
3
2.5
2
1.5
4.5
4
3.5
3
2800
BHP
0.65
0.71
0.76
0.82
0.87
0.93
0.98
1.04
1.10
1.16
1.21
1.28
1.36
1.43
1.50
1.56
Sheave/Mtr
B
B
B
A
A
A
A
A
A
A
A
A
C
C
C
C
RPM
665
705
745
780
810
845
880
910
945
975
1005
1035
1065
1095
1125
1150
Turns
Open
3
2.5
1.5
5.5
5
4.5
4
3
2.5
2
1.5
1
4
3.5
3
2.5
2900
BHP
0.71
0.76
0.82
0.87
0.92
0.98
1.03
1.09
1.16
1.22
1.29
1.36
1.43
1.50
1.57
1.63
Sheave/Mtr
B
B
A
A
A
A
A
A
A
A
A
A
C
C
C
C
RPM
685
720
760
795
825
860
890
920
955
985
1015
1045
1075
1105
1135
1160
Turns
Open
2.5
2
6
5.5
5
4
3.5
3
2.5
2
1.5
1
4
3.5
3
2.5
3000
BHP
0.78
0.84
0.89
0.95
1.00
1.06
1.12
1.18
1.24
1.30
1.37
1.43
1.50
1.58
1.64
1.71
Sheave/Mtr
B
B
A
A
A
A
A
A
A
A
A
C
C
C
C
C
RPM
700
740
775
810
845
880
910
940
970
1000
1030
1055
1085
1115
1140
1170
Turns
Open
2.5
1.5
5.5
5
4.5
4
3.5
2.5
2
1.5
1
4.5
3.5
3.5
3
2.5
3100
BHP
0.85
0.91
0.96
1.02
1.08
1.14
1.22
1.29
1.36
1.44
1.50
1.57
1.63
1.70
1.76
1.82
Sheave/Mtr
B
B
A
A
A
A
A
A
A
A
A
C
C
C
C
C
RPM
720
755
790
825
860
890
925
955
985
1015
1040
1070
1095
1125
1150
1175
Turns
Open
2
1
5.5
4.5
4
3.5
3
2.5
2
1.5
1
4
3.5
3
2.5
2
3200
BHP
0.93
1.00
1.07
1.14
1.20
1.26
1.32
1.38
1.44
1.51
1.57
1.64
1.70
1.78
1.85
1.92
Sheave/Mtr
B
A
A
A
A
A
A
A
A
A
C
C
C
C
C
C
RPM
740
775
810
845
875
905
935
965
995
1025
1050
1080
1105
1135
1160
1185
Turns
Open
1.5
5.5
5
4.5
4
3.5
3
2
1.5
1
4.5
4
3.5
3
2.5
2
A = Standard Static/Standard Motor, B = Low Static/Standard Motor, C = High Static/Standard Motor, D = Standard Static/Large Motor, E = High Static/Large Motor
Unit factory shipped with standard static sheave and drive at 2.5 turns open. Other speed require field selection.
For applications requiring higher static pressures, contact your local representative. Performance data does not include drive losses and is based on sea level condi-
tions.
Do not operate in black regions. All airflow in rated at lowest Voltage if unit is dual Voltage rated, i.e. 208V for 208-230V units.
Table Continued on Next Page
