Heat Controller, Inc.
HBH SERIES
IOM Manual
18
Electrical - Line Voltage
WARNING! To avoid possible injury or death due to
electrical shock, open the power supply disconnect switch
and secure it in an open position during installation.
CAUTION! Use only copper conductors for field installed
electrical wiring. Unit terminals are not designed to accept
other types of conductors.
�
WARNING! �
�
CAUTION! �
Transformer - All 208/230 voltage units are factory wired
for 208 volt. If supply voltage is 230 volt, installer must
rewire transformer. See wire diagram for connections.
Table 4a: HBH Series Electrical Data - (Standard 60Hz Units)
TC
Model
Voltage
Code
Rated
Voltage
Voltage
Min Max
Blower
Option
Compressor
Fan
Motor
FLA
Total
Unit
FLA
Min
Circuit
Amp
Max
Fuse/
HACR
QTY
RLA
LRA
072
H
208-3-60
197/254
A, B, C
2
10.4
73.0
4.0
24.8
27.4
35
H
208-3-60
197/254
D, E
2
10.4
73.0
6.2
27.0
29.6
35
F
460-3-60
414/506
A, B, C
2
5.8
38.0
2.0
13.6
15.1
20
F
460-3-60
414/506
D, E
2
5.8
38.0
3.1
14.7
16.1
20
N
575-3-60
518/633
A, B, C
2
3.8
36.5
1.4
9.0
9.9
15
N
575-3-60
518/633
D, E
2
3.8
36.5
2.3
9.9
10.8
15
096
H
208-3-60
197/254
A, B, C
2
13.7
83.1
6.2
33.6
37.0
50
H
208-3-60
197/254
D, E
2
13.7
83.1
9.2
36.6
40.0
50
F
460-3-60
414/506
A, B, C
2
6.2
41.0
3.1
15.5
17.0
20
F
460-3-60
414/506
D, E
2
6.2
41.0
4.3
16.7
18.3
20
N
575-3-60
518/633
A, B, C
2
4.8
33.0
2.3
11.9
13.1
15
N
575-3-60
518/633
D, E
2
4.8
33.0
3.4
13.0
14.2
15
120
H
208-3-60
197/254
A, B, C
2
15.6
110.0
9.2
40.4
44.3
50
H
208-3-60
197/254
D, E
2
15.6
110.0
14.1
45.3
49.2
60
F
460-3-60
414/506
A, B, C
2
7.8
52.0
4.3
19.9
21.9
25
F
460-3-60
414/506
D, E
2
7.8
52.0
7.0
22.6
24.6
30
N
575-3-60
518/633
A, B, C
2
5.8
38.9
3.4
15.0
16.5
20
N
575-3-60
518/633
D, E
2
5.8
38.9
5.2
16.8
18.3
20
HACR circuit breaker in USA only
All fuses Class RK-5
Electrical - Line Voltage - All field installed wiring,
including electrical ground, must comply with the National
Electrical Code as well as all applicable local codes.
Refer to the unit electrical data for fuse sizes. Consult
wiring diagram for field connections that must be made
by the installing (or electrical) contractor. All final electrical
connections must be made with a length of flexible conduit
to minimize vibration and sound transmission to the
building.
General Line Voltage Wiring - Be sure the available
power is the same voltage and phase shown on the unit
serial plate. Line and low voltage wiring must be done
in accordance with local codes or the National Electric
Code, whichever is applicable.
