IOM Manual

HBH SERIES

Heat Controller, Inc.

27

Blower Adjustment

Airflow and External Static Pressure

Selection Adjustment - The TCH Series is available with

standard, low, and high static options. These options will

substitute a different blower drive sheave for each static

range. In addition certain static ranges (bold print in Tables

5a through 5k) may require the optional large fan motor.

Please specify static range and motor horsepower when

ordering. See model nomenclature.

Sheave Adjustment - The TCH Series is supplied with

variable sheave drive on the fan motor to adjust for

differing airflows at various ESP conditions. Select an

airflow requirement on the left side of the table, then move

horizontally to right under the required ESP. Note the

sheave turns open, rpm and horsepower for that condition.

Fully closed the sheave will produce the highest static

capability (higher rpm). To adjust sheave position: loosen

belt tension and remove belt, loosen set screw on variable

sheave (on fan motor) and open sheave to desired

position. Retighten set screw and replace belt and set belt

tension as below.

Belt Tensioning - An overly loose belt will, upon motor

start, produce a slippage 'squeel' and cause premature

belt failure and or intermittent airflow. An overly tight belt

can cause premature motor or blower bearing failure.

Belt Tensioning Procedure - HBH

1. Remove belt from motor sheave

2. Lift motor assembly

3. Loosen the 5/16" hex nuts on the grommet motor

adjustment bolts (2 per bolt). To increase the

belt tension loosen the top hex nut. To decrease

the belt tension loosen the bottom hex nut.

4. Turn the bolts by hand to the desired position

then tighten the 5/16" hex nuts ( 2 per bolt).

5. Lower the motor assembly

6. Install the belt

7. The belt should be tensioned tensioning gauge

method such as the Browning Belt Tensioner to

set proper belt tension (See next page).

Notes:

- Motor position should not need adjustment.

- Motor sheave position is at mid position of each

sheave. Thus the motor sheave is typically 2.5

turns open on a 5 turn sheave.

Special Note for AHRI Testing

The Units should be adjusted as follows for rated airflow:

HBH072 - 2400cfm/2.5 turns and 0.57 in wg ESP

HBH096 - 3200cfm/3.0 turns and 0.62 in wg ESP

HBH120 - 4000cfm/3.0 turns and 0.59 in wg ESP

CAUTION!

Always disconnect all power supply(s) to unit prior to

making belt or sheave adjustments. Inadvertently starting

of the motor can cause damage to the equipment and

personal injury.
