background image

IOM Manual

HBH SERIES

Heat Controller, Inc.

35

Unit Starting and Operating Conditions

Table 9a: Operating Limits

Table 9b: Commissioning Limits

Cooling

Heating

Air Limits

Min. ambient air, DB

45ºF [7ºC]

39ºF [4ºC]

Rated ambient air, DB

80.6ºF [27ºC]

68ºF [20ºC]

Max. ambient air, DB

110ºF [43ºC]

85ºF [29ºC]

Min. entering air, DB/WB

60/50ºF [16/10ºC]

50ºF [10ºC]

Rated entering air, DB/WB

80.6/66.2ºF [27/19ºC]

68ºF [20ºC]

Max. entering air, DB/WB

95/75ºF [35/24ºC]

80ºF [27ºC]

Water Limits

Min. entering water

30ºF [-1ºC]

20ºF [-6.7ºC]

Normal entering water

50-110ºF [10-43ºC]

30-70ºF [-1 to 21ºC]

Max. entering water

120ºF [49ºC]

90ºF [32ºC]

TCH

Starting Limits

Normal Water Flow

[1.6 to 3.2 l/m per kW]

1.5 to 3.0 gpm / ton

Rev.: 24 Sept., 2009B

Cooling

Heating

Air Limits

Min. ambient air, DB

45ºF [7ºC]

39ºF [4ºC]

Rated ambient air, DB

80.6ºF [27ºC]

68ºF [20ºC]

Max. ambient air, DB

110ºF [43ºC]

85ºF [29ºC]

Min. entering air, DB/WB

50/45ºF [10/7ºC]

40ºF [4.5ºC]

Rated entering air, DB/WB

80.6/66.2ºF [27/19ºC]

68ºF [20ºC]

Max. entering air, DB/WB

110/83ºF [43/28ºC]

80ºF [27ºC]

Water Limits

Min. entering water

30ºF [-1ºC]

20ºF [-6.7ºC]

Normal entering water

50-110ºF [10-43ºC]

30-70ºF [-1 to 21ºC]

Max. entering water

120ºF [49ºC]

90ºF [32ºC]

TCH

Commissioning Limits

Normal Water Flow

1.5 to 3.0 gpm / ton

[1.6 to 3.2 l/m per kW]

Rev.: 24 Sept., 2009B

Operating Limits - Environment – Units are designed for

indoor installation only. Never install units in areas subject

to freezing or where humidity levels could cause cabinet

condensation (such as unconditioned spaces subject to

100% outside air).

Power Supply – A voltage variation of +/– 10% of

nameplate utilization voltage is acceptable.

Determination of operating limits is dependent primarily

upon three factors: 1) return air temperature. 2) water

temperature, and 3) ambient temperature. When any one

of these factors is at minimum or maximum levels, the

other two factors should be at normal levels to ensure

proper unit operation. Extreme variations in temperature

and humidity and/or corrosive water or air will adversely

affect unit performance, reliability, and service life. Consult

Table 9a for operating limits.

Starting Conditions - Starting conditions are based

upon the following notes:

Notes:

1. Conditions in Table 9b are not normal or continuous

operating conditions. Minimum/maximum limits are

start-up conditions to bring the building space up to

occupancy temperatures. Units are not designed to

operate under these conditions on a regular basis.

2. Voltage utilization range complies with AHRI

Standard 110.
