Page 49 | AlliedWare™ OS How To Note: IGMP

Static IGMP > Example

Switch 1 is an IGMP Querier and has the static IGMP entry. Static IGMP also requires you to:

z

add an IP address to the interface to which you will attach the static entry

z

enable IGMP

z

enable the interface as an IGMP interface

Switch 2 is an IGMP Snooper.

X

Configure switch 1

set system name="Switch 1"

# STP general configuration

enable stp=default

set stp=default mode=rapid

set stp=default port=1 edgeport=yes

set stp=default port=5 edgeport=yes

# VLAN general configuration

create vlan=vlan100 vid=100

add vlan=100 port=1-52

# IP configuration

enable ip

add ip int=vlan100 ip=172.31.0.254 mask=255.255.255.0

enable ip igmp

enable ip igmp int=vlan100

create ip igmp destination=224.12.13.14 int=vlan100 port=5

X

Configure switch 2

set system name="Switch 2"

# STP general configuration

enable stp=default

set stp=default mode=rapid

set stp port=2 edgeport=yes

# VLAN general configuration

create vlan=vlan100 vid=100

add vlan=100 port=1-26
