Page 16 | AlliedWare™ OS How To Note: IGMP

Multiple potential IGMP queriers > Example

Switch 1 is a potential IGMP Querier. It acts as a Snooper if it is not elected as the Querier.

Switch 2 is also a potential IGMP Querier. It acts as a Snooper if not elected as the Querier.

Switch 3 is an IGMP Snooper. It forwards multicast packets and IGMP messages as required.
IGMP snooping is enabled by default and does not need any configuration.

X

Configure switch 1

set system name="Switch 1"

# VLAN general configuration

create vlan=vlan100 vid=100

add vlan=100 port=1-52

# IP configuration

enable ip

add ip int=vlan100 ip=172.31.0.254 mask=255.255.255.0

enable ip igmp

enable ip igmp int=vlan100

# STP general configuration

enable stp=default

set stp=default mode=rapid

set stp=default port=1 edgeport=yes

X

Configure switch 2

set system name="Switch 2"

# VLAN general configuration

create vlan=vlan100 vid=100

add vlan=100 port=1-26

# IP configuration

enable ip

add ip int=vlan100 ip=172.31.0.253 mask=255.255.255.0

enable ip igmp

enable ip igmp int=vlan100

# STP general configuration

enable stp=default

set stp=default mode=rapid

set stp port=2 edgeport=yes

X

Configure switch 3

set system name="Switch 3"

# VLAN general configuration

create vlan=vlan100 vid=100

add vlan=100 port=1-26

# STP general configuration

enable stp=default

set stp=default mode=rapid

set stp port=3 edgeport=yes
