Page 41 | AlliedWare™ OS How To Note: IGMP

IGMP throttling (limiting the number of streams for each subscriber) > Example

Switch 1 is an IGMP Querier. Note that it has a filter configured on it, which is from the
previous example.

Switch 2 is an IGMP Snooper. IGMP snooping is enabled by default and does not need any
configuration. Switch 2 is limited to six multicast groups on port 2.

X

Configure switch 1

set system name="Switch 1"

# STP general configuration

enable stp=default

set stp=default mode=rapid

set stp=default port=1 edgeport=yes

# VLAN general configuration

create vlan=vlan100 vid=100

add vlan=100 port=1-52

# Switching configuration

set switch port=1 igmpfilter=1

# IP configuration

enable ip

add ip int=vlan100 ip=172.31.0.254 mask=255.255.255.0

enable ip igmp

enable ip igmp int=vlan100

create igmp filter=1

add igmp filter=1 entry=1 group=224.0.1.22 action=exclude

add igmp filter=1 entry=2 group=224.0.0.0-224.255.255.255

X

Configure switch 2

set system name="Switch 2"

# STP general configuration

enable stp=default

set stp=default mode=rapid

set stp port=2 edgeport=yes

# VLAN general configuration

create vlan=vlan100 vid=100

add vlan=100 port=1-26

# Switching configuration

set switch port=2 igmpmaxgroup=6 igmpaction=replace
