VertX V100, V200 and V300 Installation Guide
Introduction
HID’s VertX open platform is flexible and scalable to permit economic and high performance access control
solutions for a wide range of applications. The VertX units interconnect through different sub-networks and
protocols to a standard TCP/IP network with the capability of a variety of applications.
The VertX Interface Panels are designed for control by a VertX V1000 Access Controller. The V100
Door/Reader Interface panel controls two sets of door devices or one door with Card In/Card Out (a reader
on both sides of the same door). The V200 Input Monitor Interface panel monitors as many as 16 input
points. The V300 Output Control Interface panel controls as many as 12 output relays.
Parts List
V100, V200 and V300 Quantity
Interface Panel 1
Mounting screws 4
2.2K EOL resistors 32
Quick Installation Guide 1
Note: VertX Interface panels require installing a V1000 Controller. See the V1000 Wiring Diagram Example.
Product Specifications
Description Specification
Power Supply 12-16VDC
Maximum Current at 12VDC per unit 1 Amp
Average operating current at 12VDC V100 - 450mA (with two R40 iCLASS Readers)
V200 - 60mA
V300 - 75mA
Operating temperature range 32°-120°F (0°-49°C)
Humidity 5% to 85% non-condensing
