Chapter 4 X-Switch CLI & ATM Terminal Interface
Avaya M770 M-ACCF/SF ATM Access Modules User’s Guide 67
Figure 4.12 Display Results
ATM Port Physical Submenu [2,1,6]
The ATM Port Physical submenu allows you to set the ATM Port Speed (either
OC-12c or OC-3c)[1], the framing protocol SONET/SDH, fast link recovery state
and ILMI synchroniztion mode.
Figure 4.13 ATM Port Physical Submenu
VCC Submenu [2,2]
The VCC submenu enables you to see ATM VCC attributes and display statistics
and settings. See Figure 4.14.
Admin Status : Up
Oper Status : Up
UNI version : 3.1
ILMI VCC : 0/16
Signaling VCC : 0/5
Signaling Time Resolution : 100
Speed : OC-12
Type : SONET
Fiber mode : MULTI
Fast link recovery state : On
ILMI synchronization mode : Enable
ATM Port Physical Menu
======================
[1] speed - Change port speed OC-3/OC-12c
[2] type - Change port physical type SONET/SDH
[3] fast - Change fast link recovery state
[4] sync - Change ILMI synchronization mode
