Page 41
Chapter 1
Overview
Avaya M770 M-ACCF/SF ATM Access Modules User’s Guide
25
Note:
ELAN-to-VLAN and VLAN-to-ELAN mapping is only one-to-one.
Unassociated packets/cells are discarded.
Figure 1.16
VLAN to ELAN Mapping
Lecturer
LEC
Lecturer
LEC
Lecturer
ELAN
Lecturer
VLAN
Lecturer
VLAN
Admin
LEC
Admin
LEC
Admin
ELAN
Admin
VLAN
Admin
VLAN
Student
LEC
Student
LEC
Student
VLAN
Virtual Network
Student
VLAN
Student
ELAN
Avaya M770
Multifunction Switch
Avaya M770
Multifunction Switch
ATM
Network
