Chapter 2 Applications
Avaya M770 M-ACCF/SF ATM Access Modules User’s Guide 33
Avaya M770 Multitechnology Functionality
This section gives an example of ATM within a WAN environment connecting
various sites. Using the M-ACC module we can leverage the Multifunctionality of
the Avaya M770 and connect Fast Ethernet PC desktops to the same single chassis.
In Figure 2.2, ATM was chosen to efficiently transfer both voice and data on a single
trunk. The diagram demonstrates the balance between cost and performance
requirements by the use of a single high performance Avaya M770. The M-ACC
module connects the ATM and Ethernet domains in the Avaya M770.
Figure 2.2 Avaya M770 Multitechnology Functionality
DS-3
DS-3
OC-3
OC-3
10/100
10/100
10/100
10/100
OC-12
OC-12
OC-12
OC-12
OC-12
OC-12
Avaya M770
Avaya M770 Avaya M770
Avaya M770
OC-48
DEFINITY Server
10/100
Avaya M770
DEFINITY Client
DEFINITY Client
DEFINITY Client
DEFINITY Client
OC-3
ATM
WAN
DS-3
