Page 62
Chapter 3
Installation
46
Avaya M770 M-ACCF/SF ATM Access Modules User’s Guide
Module Setup Main Menu
Setup Main Menu
M-ACCF S/W Version: 4.0.7 Slot #: 5
0. Return to Previous Menu
-----------------------------------
1. Reset the Module
2. Software Download …
3. Set Primary Version …
4. Set Factory Defaults
5. Create Report
6. Clear Mac Address Table
7. Configuration Copy
8. ATM IP Configuration …
>>>Enter your choice:
The module Setup Main Menu lists the various categories of M-ACC configurable
parameters. You have the 8 options listed above.
ATM IP Configuration
Option 8 from the Main Menu 'ATM IP Configuration', allows you to show and set
the IP Configuration of the ATM entity of the M-ACC.
ATM IP Configuration Menu
-------------------------
0. Return to Previous Menu
1. Set IP Configuration
2. Show IP Configuration
Please enter your choose:2
IP Address Netmask Default Gateway
--------------- --------------- ---------------
149.49.54.249 255.255.255.0 149.49.54.1
Assigning the M-ACC module IP address, Gateway and Netmask:
1
Select Option 1 “Set IP Configuration”
2
Check that the LED labelled OPR, on the ATM access module front panel is ON.
3
Type the IP address, net mask and default gateway of the ATM access module
when prompted.
