Setting up the M-ACC Module
Before you can set up the M-ACC module you must power on and set up the
Avaya M770 switch as described in the Avaya M770 User Guide.
The following steps describe how to configure the M-ACC module using the
Avaya M770 CLI.
Changing the Default IP Address of the M-ACC Module Using the CLI
To begin using the ATM access module you must first assign an IP address and
ATM capabilities to the module via the CLI of the X-switch CPU.
You can either connect a VT-100 terminal or PC with VT-100 emulation to the Console
port of the M-SPX/S Supervisor module or Telnet the M-SPX/S IP address.
To connect to the M-SPX/S Console port
1
Use the serial cable supplied to attach the RJ-45 console connector to the
Console port of the M-SPX/S Supervisor module and the DB-9 connector to the
serial (COM) port on your PC/terminal.
2
Ensure that the serial port settings on the PC are 9600 baud, 8 bits, 1 stop bit and
no parity.
3
If you connected a PC, run a VT-100 emulation session. (You can use the
Windows® HyperTerminal.)
4
After the M-ACC enters setup mode, you are prompted to enter a user name
and password. Type the Login Name super and Password super and Enter
(only if you are connected via Telnet).
5
The Switch Main Menu displays:
Switch Main Menu
----------------------------------
Select an Agent to configure:
0. Return to Previous Menu
1. Direct Access to specific module
2. M-SPX in slot: 15
manages modules: 3,4,5,7,9,10,11
>>>Enter your choice
When you choose Option 1 and enter the M-ACC slot number, you reach the
M-ACC’s Setup Main Menu.
