Installation Instructions
B254
Erlenmeyer Outdoor Sconce 30-7710 & 307715 Page 2 of 2
Hand-Forged, Vermont-Made Lighting and Accessories
154 Route 30 South, Castleton, Vermont 05735 26975
6. Carefully tuck all wires behind the fixture assembly and inside the wall mount bracket and place the fixture firmly
onto bracket (B) and fasten with #8 black screw (E) and rubber washer (F) on top.
7. Install 2 nd set of black screws (E) in bottom of fixture attaching to wall mounting bracket (B).
To Install Glass (Figure 3)
Component Parts
A Fixture Assembly
J Bulb (Included)
K Glass
L Thumb Screw (3)
1. Install bulb (J). Be careful not to touch bulb with bare hands;
oil from the hands will dramatically reduce bulb life.
2. Loosen the three thumb screws (L). It is not necessary to
remove them from the fixture.
3. Raise glass (K) until groove is aligned with thumb screws (L).
4. Tighten the three thumb screws (L) equal amounts until snug
with glass (K). Be careful not to over tighten.
5. Restore electricity at main breaker.
If you need further assistance, or find that you are missing any parts, please contact the dealer from which you purchased
this product. We hope you enjoy your fixture!
*
Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use of this fixture.
(Figure 3)
