Shade Installation Instructions

If you need further assistance, or find that you are missing any parts, please contact the dealer from which you purchased this product.
We hope you enjoy your fixture!

* Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use of this fixture.

To Install Glass Diffuser

(Figures 1 & 2)

Component Parts

A Finial

B Washer

C Diffuser

D Shade

E Socket

F Threaded Stud

1. Carefully unpack the lamp from the carton.

2. Remove finial (A) and washer (B) from threaded stud (F) and

save for later use. Finial and washer are shipped installed.

3. Install bulbs. “C” version bulbs are included.

4. Slip shade (D), diffuser (C) and washer (B) onto threaded

stud (F). See Figure 2 for washer orientation.

5. Thread finial (A) onto threaded stud (F) on socket (E) and

tighten until snug. Be careful not to over tighten.

C63

Balance Table Lamp 274101 & 274101C

Page 1 of 1

(Figure 1)

(Figure 2)

FINIAL

WASHER

TOP OF DIFFUSER

CORRECT ORIENTATION

WRONG ORIENTATION
