Installation Instructions
B124
For Swing Arm Sconce 20-9250 Page 2 of 2
Hand-Forged, Vermont-Made Lighting and Accessories
P.O. Box 827, 154 Route 30 South, Castleton, Vermont 05735 20851 Rev A
To Install Glass & Shade (Figure 3)
Component Parts
H Retaining Ring
I Shade
J Glass
Diffuser
K Socket
1. Slip glass diffuser (J) over socket (K).
2. Slip center ring of shade (I) over socket until it rests on top
of diffuser glass (J).
3. Thread retaining ring (H) onto socket until it rests on top of
shade (I). Do not over tighten.
4. Install light bulb(s) and restore electricity at main breaker.
If you need further assistance, or find that you are missing any parts, please contact
the dealer from which you purchased this product. We hope you enjoy your fixture!
* Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use of this fixture.
(Figure 3)
