Installation Instructions
B186
For Antasia Wall Sconce 20-4720 Page 2 of 2
Hand-Forged, Vermont-Made Lighting and Accessories
P.O. Box 827, 154 Route 30 South, Castleton, Vermont 05735 22813
(Figure 2)
(Figure 3)
To Install Glass (Figure 2)
Component Parts
A Fixture Assembly
H Glass
I
Nylon Screw (2)
J Bracket
K Wireway
1. Loosen two nylon screws (I) installed into
bracket (J). Screws are shipped installed.
2. Slip glass (H) so that notch in glass matches up
with wireway (K).
3. Tighten nylon screws (I) against glass (H) until
snug.
To Install Diffuser
(Figure 3)
Component Parts
L Diffuser
M Bulb
N Bulb
Shield
O Socket
P Screw
1. Install light bulb (M). Be careful not to touch bulb with bare
hands; oil from the hands will dramatically reduce bulb life.
2. Thread bulb shield (N) onto socket (O) (be careful not to over
tighten). Future bulb changes may be accomplished by
snapping glass portion of barrier on and off rather than
unthreading the holder.
3. Install diffuser (L) onto fixture followed by flat head screw (P).
Tighten screw until snug.
4. Restore electricity at main breaker.
If you need further assistance, or find that you are missing any parts, please contact the dealer from which you purchased
this product. We hope you enjoy your fixture!
* Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use of this fixture.
