Installation Instructions
A212
For Beacon Hall Four Light Chandelier 10-4815 & 10-4815E Page 2 of 2
Hand-Forged, Vermont-Made Lighting and Accessories
P.O. Box 827, 154 Route 30 South, Castleton, Vermont 05735 22850
To Install Glass
(Figure 2)
Component Parts
K Socket (4)
L Glass (4)
M Retaining Ring (4)
N Socket
Tool
1. Remove retaining rings (M) from sockets (K). Retaining
Rings are shipped installed.
2. Slip glass (L) over socket (K).
3. Thread retaining ring (M) onto socket (K) using provided
socket tool (N) provided until it rests on inside of glass (L). Do
not over tighten.
4. Install light bulbs. “E” version bulbs are included.
To Install Shade
(Figure 3)
Component Parts
O Shade
P Knurl
Balls (4)
Q Threaded Stud (4)
R Shade
Bracket
1. Remove four knurl balls (P) that are shipped
installed. Save for later use.
2. Raise shade (O) from bottom until the top clears
the shade bracket (R) and slip over threaded
studs (Q).
3. Thread four knurl balls (P) on to threaded studs
(Q) until snug.
4. Restore electricity at main breaker.
If you need further assistance, or find that you are missing any parts, please contact the dealer from which you purchased
this product. We hope you enjoy your fixture!
* Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use of this fixture.
(Figure 2)
(Figure 3)
