Installation Instructions

A306

Flora Chandelier 10-3043

Page 2 of 2

Hand-Forged,

Vermont-Made Lighting and Accessories

154 Route 30 South, Castleton, Vermont 05735

27185

To Install Single Glass Option

(Figure 2)

Component Parts

J Socket
K Bulb

(Included)

L Glass
M Retaining

Ring

N

Retaining Ring Tool

1. Remove retaining ring (M) from socket (J) and retain. Retaining ring ships

installed.

2. Install light bulb (K). Be careful not to touch bulb with bare hands; oil from

the hands will dramatically reduce bulb life.

Note: The bulb included is based on our design preference; see the fixtures
wattage sticker for Max wattage information.

3. Slip glass (L) over socket (J) and thread retaining ring (M) onto socket (J)

using provided retaining ring tool (N).

4. Repeat steps 1-3 for remaining sockets.
5. Restore electricity at main breaker.


To Install Double Glass Option

(Figure 3)

Component Parts

J Socket
K Bulb

(Included)

L Glass
M Retaining

Ring

N

Retaining Ring Tool

O Inner

Glass

1. Remove retaining ring (M) from socket (J) and retain. Retaining ring

ships installed.

2. Install light bulb (K). Be careful not to touch bulb with bare hands; oil

from the hands will dramatically reduce bulb life.

Note: The bulb included is based on our design preference; see the
fixture wattage sticker for Max wattage information.

3. Place inner glass (O) inside glass (L) and then slip glass (L) over socket

(K). Thread retaining ring (M) onto socket (J) using provided retaining
ring tool (N).

4. Repeat steps 1-3 for remaining sockets.
5. Restore electricity at main breaker.



If you need further assistance, or find that you are missing any parts, please
contact the dealer from which you purchased this product. We hope you
enjoy your fixture!

* Hubbardton Forge will not be liable for injury or damage caused by improper
installation, lamping or use of this fixture.

(Figure 2)

(Figure 3)
