If you need further assistance, or find that you are missing any parts, please contact the dealer from which you purchased this product.
We hope you enjoy your fixture!

* Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use of this fixture.

H U B B A R D T O N F O R G E . C O M

hand-forged, vermont-made lighting and accessories

154 RT. 30 SOUTH

•

CASTLETON, VERMONT 05735

30648

Assembly & Installation Instructions

To Mount Fixture to Wall

(Figure 1)

7. Thread the wires in the electrical box through the hole in the

mounting bracket (B) while moving the bracket into position.

Using the 1" #10 screws (D), screw the bracket securely to

the wall. Be careful not to over-tighten or strip the anchors.

8. Hold the fixture (A) close to the mounting bracket (B) and

using suitable wire connectors (not provided) connect fixture

wires to supply wires (white to white and black to black).

Run a pigtail lead from the ground screw (F) and cupped

washer (E) to the electrical box and connect all ground wires

(bare copper or green to bare copper or green).

CAUTION: MAKE SURE WIRE CONNECTORS ARE TWISTED ON SE-
CURELY, AND NO BARE WIRES ARE EXPOSED.

9. Carefully tuck all wires behind the fixture (A) and inside the

mounting bracket (B) and place the fixture firmly onto

bracket (B) and fasten with #8 black screws (H) on top.

10. Install remaining black screw (H) in bottom of fixture (A)

attaching to mounting bracket (B).

11. Restore electricity at main breaker.

B321

Helix Sconce 207430

Page 2 of 2

(Continued)
