Allied Telesis AT-WA7501 - Manual (Page 299)

AT-WA7500 and AT-WA7501 Installation and User’s Guide
299
AT-7500 Access Point
Table 80. AT-7500 Technical Specifications
Dimensions H x L x W
4.6 cm x 25.0 cm x 15.9 cm
(1.8 in x9.8 in x 6.3 in)
Weight 526 g (1.16 lb)
POE Electrical Rating x 48V, 315 mA
Operating temperature
-20
o
C to +55
o
C (-4
o
F to +131
o
F)
Storage temperature
-40 o C to +70 o C (-40 o F to +158 o F)
Humidity (non-condensing) 10 to 90%
Architecture Transparent bridge
Ethernet interfaces 10Base-T/100Base-TX (twisted-pair)
Ethernet compatibility Ethernet frame types and Ethernet addressing
Ethernet data rate 10 Mbps/100 Mbps (Ethernet)
Radios supported IEEE 802.11g, IEEE 802.11b, IEEE 802.11a
Media Access protocol CSMA/CD
Filters (protocol) IP, IPX, NetBEUI, DECNET, AppleTalk
Filters (others) IP, ARP, Novell RIP, SAP, LSP
Serial port maximum data
rate 115,200 bps
Management interfaces Web browser-based manager, text-based menu
system, serial port, Telnet, SNMP
SNMP agent RFC 1213 (MIB-2), RFC 1398 (dot3), RFC 1493
(Bridge), 802.11, 802.1x
Regulatory Approvals EN 550022/CISPR 22 Class A; FCC Part 15 &
ICES-003 Class A; C tick Marked (AS 3548); CE
Market, Compliant with RTT&E, EMC, LVD
directives; (See separate radio approvals); UL
Listed 1950 & IEC 60529-IP53; CSA Certified,
C22.2 #950 & C22.3 #94-ENC 3.5; TUV
Licensed, EN 60950 & EN 60529-IP53; NYCE
Certified, NOM 19, plenum-rated
