Allied Telesyn AT-VIEW PLUS
VLAN MANAGER
6.15 AT-RG600 Series
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
6.15.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports This is a list of the untagged member ports of the VLAN.
Priority This indicates the 802.1p Priority.
Status
This indicates the status of the VLAN.
• static
Note - VLANs whose names start with a number cannot be deleted.
6.15.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs have the following Input Fields:
Input Field Valid Values Length
Name (cannot be
modified)
• Alphanumeric characters
• Underscore ("_")
• Dash ("-")
Note - VLAN names cannot start with a digit and cannot
contain period '.' or slash symbols '/'.
1 - 15 characters
Identifier (cannot
be modified) • 1 - 512 (AT-RG656BD)
• 1 - 4094 (AT-RG613TX / AT-RG613SH)
-
Priority (cannot be
modified)
• 0 - 7
Note - This field is implemented as a drop-down list.
-
PN 613-50666-00 Rev C Page 58 of 59
