Allied Telesyn
AT-VIEW PLUS
VLAN MANAGER
6.7 AT-8500 Series
Topics:
•
•
6.7.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name
Description
Name
This is the name of the VLAN.
Identifier
This is the unique identifier of the VLAN.
Tagged Ports
This is a list of the tagged member ports of the VLAN.
Untagged Ports
This is a list of the untagged member ports of the VLAN.
Status
This indicates the status of the VLAN.
•
active
•
not in service
•
not ready
•
create and go
•
create and wait
•
destroy
Note
- If the selected Uplink Port is not connected to the Uplink VLAN, and the VLAN Mode is
set to Multiple VLAN or 802.1Q Multiple VLAN, the connection with the device will be lost.
Furthermore, no warning message will be displayed before the connection is lost.
Note
- The current firmware version does not allow the Default VLAN to be modified. As a
result, all AT-View Plus VLAN Manager operations involving the Default VLAN will fail.
Note
- For 20-character VLAN Names entered via telnet, only the first 19 characters are
registered in VLAN Manager.
Note
- AT-8550 : Changing the VLAN Mode parameter setting from '802.1Q Multiple VLAN' to
a different mode may result in the error message: "Unable to communicate. Confirm SNMP
settings or login, and if the network is functional." However, VLAN Mode is still set to the new
mode successfully. To prevent this error message from reappearing, go to File -> Properties and
increase the Retry Timeout value.
