6.10 AT-8900/AT-9900 Series
Topics:
•
•
6.10.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name
Description
Name
This is the name of the VLAN.
Identifier
This is the unique identifier of the VLAN.
Operation Mode
This indicates the operation mode of the VLAN.
Type
This indicates the type of the VLAN.
•
Port-based
•
Multiple Type
Tagged Ports
This is a list of the tagged member ports of the VLAN.
Untagged Ports
This is a list of the untagged member ports of the VLAN.
Uplink Port
This is a list of the uplink ports of the VLAN.
Private Ports
This is a list of the private ports of the VLAN.
Core Ports
This is a list of the core ports of the VLAN.
Customer Ports
This is a list of the customer ports of the VLAN.
Status
This indicates the status of the VLAN.
•
dynamic
•
static
Note
- When adding/modifying a Nested VLAN, specifying a port that is already a member of an
existing Normal VLAN will not generate any error. However, the specified port will be ignored.
In addition, during modification, existing member ports having the same status (tagged/untagged)
as the specified port will be deleted.
Note
- When importing the default VLAN, VLAN Manager disregards the values specified for
Untagged Ports.
Note
- For the Import VLAN operation:
•
If the specified Operation Mode is Normal - the Uplink Ports, Private Ports, Core Ports
and Customer Ports fields will be ignored.
