Allied Telesyn AT-VIEW PLUS
VLAN MANAGER
6.2 AT-8124XL (v2)
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
6.2.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports This is a list of the untagged member ports of the VLAN.
Status
This indicates the status of the VLAN.
• idle
• operational
• under-construction
• not-operational
Note - An error message, "An error occurred during the operation. Error: Read only" will be
displayed when the user tries to modify the Default VLAN.
Note - After an Import VLAN operation of Multiple VLANs, all VLANs with valid VLAN
definitions will have a successful status except for the Default VLAN.
6.2.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs display the following Input Fields:
Input Field Valid Values Length
Name
• Alphanumeric characters
• Underscore ("_")
• Dash ("-")
0 - 20 characters
Identifier 1 - 4094 -
6 Device Support
PN 613-50666-00 Rev C Page 34 of 59
