Allied Telesyn AT-VIEW PLUS
VLAN MANAGER
6.11 AT-9400 Series
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
6.11.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports This is a list of the untagged member ports of the VLAN.
Status
This indicates the status of the VLAN.
• idle
• operational
• under-construction
• not-operational
Note - If the selected Uplink Port is not connected to the Uplink VLAN, and the VLAN Mode is
set to Multiple VLAN or 802.1Q Multiple VLAN, the connection with the device will be lost.
Furthermore, no warning message will be displayed before the connection is lost.
Note - The current firmware version does not allow AT-View Plus VLAN Manager to
distinguish between Protected VLANs and standard Port-based VLANs. As a result, AT-View
Plus VLAN Manager will display and treat Protected VLANs as if they were standard Port-based
VLANs. Furthermore, modifying a Protected VLAN will convert that VLAN into a standard
Port-based VLAN.
Note - The current firmware version does not allow the Default VLAN to be modified. As a
result, all AT-View Plus VLAN Manager operations involving the Default VLAN will fail.
Note - The VLAN Mode parameter can only be set to a different mode if it is currently set to
'User Configured VLAN'. However, changing the mode from 'User Configured VLAN' to
'Multiple VLAN' will set VLAN Mode to '802.1Q Multiple VLAN'. On the other hand, changing
the mode from 'User Configured VLAN' to '802.1Q Multiple VLAN' will set VLAN Mode to
'Multiple VLAN'.
Note - For 20-character VLAN Names entered via telnet, only the first 19 characters are
registered in VLAN Manager.
