Allied Telesyn AT-VIEW PLUS
VLAN MANAGER
6.3 AT-8200XL Series
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
6.3.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Member Ports This is a list of the member ports of the VLAN.
Untagged Ports
This is a list of the untagged (port-based) member ports of the
VLAN.
Status
This indicates the status of the VLAN.
• idle
• operational
• under-construction
• not-operational
Note - An error message, "An error occurred during the operation. Error: Bad Value." will be
displayed when the user tries to modify the Default VLAN.
Note - An error message, "An error occurred during the operation. Error: The device is in
Multiple VLAN mode. Pre-configured VLANs cannot be displayed for this device." will be
displayed when the VLAN Mode is set to Multiple VLAN and the VLAN definitions for the
multiple VLANs were not displayed in the VLAN Information Window.
Note - After an Import VLAN operation of Multiple VLANs, all VLANs with valid VLAN
definitions will have a successful status except for the Default VLAN.
Note - After an Import VLAN operation, VLAN definitions with out of range Member Ports will
have a successful status.
Note - If the selected Uplink Port is not connected to the Uplink VLAN, and the VLAN Mode is
set to Multiple VLAN or 802.1Q Multiple VLAN, the connection with the device will be lost.
Furthermore, no warning message will be displayed before the connection is lost.
