Allied Telesyn AT-VIEW PLUS
VLAN MANAGER
6.5 AT-8300GB Series
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
6.5.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
- Tagged Ports
This is a list of the tagged member ports of the VLAN that belong
to a specific module on the stack.
- Untagged
Ports This is a list of the untagged member ports of the VLAN that
belong to a specific module on the stack.
Status
This indicates the status of the VLAN.
• idle
• operational
• under-construction
• not-operational
Note - Ports in the Default VLAN cannot be changed from untagged to tagged.
Note - VLAN definitions that only contain tagged ports cannot be deleted.
Note - VLAN definitions that only contain tagged ports cannot be deleted during an Import
VLAN operation.
Note - The retry timeout must be set to a higher value when adding or modifying VLAN
definitions. The timeout value varies depending on the number of devices in the stack.
PN 613-50666-00 Rev C Page 39 of 59
